Mini Illuminance Meter LI-500M

Measuring range:0~200000Lux; 0~20000Fc
Accuracy: ±3%rdg±10dgts(≤10000Lux)
Resolution 1 Lux
Sampling rate 2 times/sec
Repeatability test ±2%
Unit: Lux, Fc

Category:

Description

  • LI-500M is a special instrument for measuring illuminance, which can be used in factories, lighting industry, planting industry, schools, offices, laboratories, street lamp construction and so on.
  • LI-500M is equipped with a high-sensitivity photosensitive probe, which can measure even in low-light environments. Its large range of 0~200000Lux can meet the measurement requirements of users in different environments.
  • LI-500M has two measurement modes to choose from. Among them, in the maximum or minimum measurement mode, the maximum or minimum displayed by the instrument will change according to the real-time measurement results, and the user can obtain the current measured maximum or minimum illuminance value at any time.
  • LI-500M has a key buzzer prompt function, the user can choose to open or close this function. After it is turned on, the user only needs to perform a valid key operation, and the instrument will beep.
  • LI-500M is small and light, with an integrated design, which can be carried with you.
Features:
  • High sensitivity probe
  • Automatic range
  • Two illuminance units
  • Max/Min measurement mode
  • Button buzzer prompt
  • Value lock(HOLD)
  • Screen with backlight
  • Automatic shutdown
  • Battery protection
  • Battery level prompt



Datasheet

Model

LI-500M

Measuring range

0~200000Lux; 0~20000Fc

Accuracy

±3%rdg±10dgts(≤10000Lux); ±4%rdg±10dgts(Other range)

Resolution

1 Lux

Sampling rate

2 times/sec

Repeatability test

±2%

Unit

Lux, Fc

Operating environment

Temperature: -10~50℃; Humidity: 10~90%RH

Storage environment

Temperature: -10~55℃; Humidity: 10~95%RH

Power supply

3 AAA 1.5V alkaline batteries; 3 AAA 1.2V rechargeable batteries

Dimensions

163*55*28mm

Protection level

IP40

Shell material

ABS

Weight

About 90g (Without battery)

Video

Video

User Manual

FAQ

1-Can I customized with own logo?
